How does the Masoneilan method calculate control valve sizing for two-phase flow?

The Masoneilan method calculates the required flow coefficient (Cv) by splitting the fluid components into liquid and gas weight fractions. It combines their respective effective pressure drops, densities, and the expansion factor (Y) for the gas phase into a single integrated equation to determine the overall Cv.

What is the significance of the expansion factor Y in two-phase valve flow?

The expansion factor Y accounts for the change in density of the gas phase as it accelerates and expands through the control valve restriction. It relies on the ratio of specific heats factor and the critical pressure drop ratio.

How do you determine if a phase is choked during two-phase flow through a control valve?

The liquid phase is choked if the actual pressure drop exceeds the choked limit calculated from the critical flow factor FL and vapor pressure. The gas phase is choked when the pressure drop ratio exceeds the limits of Fk * xT. The sizing equation uses the minimum of actual and choked pressure drops for each phase.

Control valves for 2 phases flow

Calculation of Cv and mass flow through a control valve operating in 2 phases flow

Follow us on Twitter
Question, remark ? Contact us at contact@myengineeringtools.com

1. Cv and Kv definition

What is the flow coefficient Cv and Kv - calculation of flow through a valve - SI units

Please refer to the valve flow coefficient page of Process Engineer's tools.

2. Calculation of Cv and flow through a valve - Case of 2 phases flow - metric units

What is the Cv required for a valve in 2 phases flow service ?

When a valve is operated in a bi‑phasic flow at the valve inlet, the Cv required for a given mass flow rate can be estimated thanks to the following formula [Masoneilan]; for a deeper understanding of how this Cv relates to the Kv flow factor and how to convert between the two, see the guide on Cv versus Kv conversion and interpretation.

\[ C_v = \frac{\dot{m}}{27.3 \cdot F_p} \cdot \sqrt{ \frac{f_f}{\Delta P_f \cdot \gamma_f} + \frac{f_g}{\Delta P_g \cdot \gamma_g \cdot Y^2} } \]

With

\(\dot{m}\)=Flow rate (\(\text{kg/h}\))
\(F_p\) = piping geometry factor (reducer correction), it is = 1 if the valve size is equal to the pipe size
\(C_v\)=valve flow coefficient (GPM)
\(f_f\) = weight fraction of liquid in 2 phases flow (-)
\(f_g\) = weight fraction of gas in 2 phases flow (-)
\(\Delta P_f\) = effective pressure drop of liquid phase (\(\text{bar}\))
\(\Delta P_g\) = effective pressure drop of gas phase (\(\text{bar}\))
\(\gamma_f\) =mass density of the liquid phase at inlet conditions (\(\text{kg/m}^3\))
\(\gamma_g\) =mass density of the gas phase at inlet conditions (\(\text{kg/m}^3\))
\(Y\) = expansion factor = \(1 - \frac{x}{3 \cdot F_k \cdot x_T}\)

\(x\) = pressure drop ratio = \(\Delta P/P_1\) (-)
\(P_1\) = upstream pressure (\(\text{bar abs}\))
\(F_k\) = ratio of specific heat factors = \(k/1.40\)
\(k\) = gas specific heat ratio
\(x_T\) = pressure drop ratio factor (this value is supplied by the constructor of the valve in product brochure). Note the value of \(x_T\) can be taken as such only if the valve is used without reducers ; if used with reducers it should be corrected)

How to calculate \(\Delta P_f\) and \(\Delta P_g\) ?

\[ \Delta P_f = F_L^2 \cdot (P_1 - F_F \cdot P_v) \] \[ \Delta P_g = F_k \cdot x_T \cdot P_1 \]

With

\(\Delta P_f\) = pressure drop of liquid phase (\(\text{bar}\))
\(F_L\) = critical flow factor (given by the valve manufacturer)
\(P_1\) = upstream pressure (\(\text{bar abs}\))
\(F_F\) = liquid critical pressure factor = \(0.96-0.28 \cdot \sqrt{P_v/P_c}\)
\(P_v\) = vapor pressure of liquid at flowing temperature (\(\text{bar abs}\))
\(P_c\) = pressure at thermodynamic critical point (\(\text{bar abs}\))
\(F_k\) = ratio of specific heat factors = \(k/1.40\)
\(k\) = gas specific heat ratio
\(x_T\) = pressure drop ratio factor

⚠️ ENGINEERING NOTICE & EDUCATIONAL DISCLAIMER: This interactive calculator is provided exclusively for preliminary estimation and educational purposes. It is not intended for detailed design or equipment procurement without certified vendor rating. No warranty, expressed or implied, is provided, and no liability is assumed.

🎛️ Control Valve 2-Phase Flow Calculator

SI Metric (bar, kg/h, kg/m³) US Customary (psi, lb/h, lb/ft³)

📐 Sizing Mode (Calculate Cv) ⚙️ Rating Mode (Evaluate Capacity)

Mass Flow Rate (ṁ) (kg/h)

Installed Cv (GPM)

Piping Geometry Factor (F_p)

Liquid Weight Fraction (f_f)

Gas Weight Fraction (f_g)

Upstream Pressure (P₁) (bar abs)

Pressure Drop (ΔP) (bar)

Gas Specific Heat Ratio (k)

Pressure Drop Ratio Factor (x_T)

Critical Flow Factor (F_L)

Vapor Pressure (P_v) (bar abs)

Critical Pressure (P_c) (bar abs)

Liquid Density (γ_f) (kg/m³)

Gas Density (γ_g) (kg/m³)

📋 Industrial Sizing Best Practices & Safety Limits

Erosion Control: Two-phase flow is highly erosive. Avoid carbon steel bodies; specify Chrome-Moly (WC9) or Stainless Steel (CF8M) valve bodies with hardened trim (Stellite facing) to prevent premature failure.
Kinetic Energy Limit: Keep the outlet kinetic energy parameter \(\rho_{\text{mix}} v^2\) below \(20,000 \text{ kg/(m}\cdot\text{s}^2\text{)}\) to prevent excessive vibration and acoustic fatigue.
Flashing and Cavitation: When liquid vapor pressure \(P_v\) exceeds the outlet pressure, flashing occurs. Flashing is an unavoidable physical phenomenon; use sweep-angle valves or tortuous path trims to direct the abrasive mixture away from the valve walls.
Line Sizing vs. Valve Sizing: Due to rapid gas expansion, a line-size valve is often required in high-vapor-fraction services, even if a smaller trim is chosen. Sizing the valve body to match the pipe helps avoid high downstream nozzle velocities.

Source

Masoneilan Control Valve Sizing Handbook, 2000
